• Customized • Higher Jar Quality • Enery Saving • Direct connection with Wide Mouth Preform Production Line
TYPE |
ITEM |
YW-L2-130 |
YW-L2-152 |
YW-L4-130 |
YW-L6-80 |
CONTAINER |
Cavity Qty |
2 |
2 |
4 |
6 |
Output |
1800-2200BPH |
1600-2000BPH |
3400-3600BPH |
4500-5000BPH |
|
Max.Container Volume |
2.5L |
4L |
2.5L |
0.75L |
|
Pitch Distance |
130mm |
150mm |
130mm |
80mm |
|
Max Neck Diameter |
100mm |
125mm |
100mm |
65mm |
|
Max.Container Diameter |
120mm |
140mm |
120mm |
70mm |
|
Max.Container Height |
350mm |
350mm |
350mm |
250mm |
|
ELECTRICAL SYSTEM |
Lamp Qty |
32pcs |
60pcs |
40pcs |
36 pcs |
Max.Heating Powe |
48kw |
90kw |
60kw |
54 kw |
|
Installation Power |
56kw |
99kw |
72kw |
66kw |
|
Actual Power Consumption |
20-25kw |
30-35kw |
25-30kw |
25-30kw |
|
AIR SYSTEM |
Operating Pressure |
7kg/cm2 |
7kg/cm2 |
7kg/cm2 |
7kg/cm2 |
Low Pressure Air Consumption |
1600Ltr/min |
1600Ltr/min |
1600Ltr/min |
1600Ltr/min |
|
Blowing Pressure |
≤30kg/cm2 |
≤30kg/cm2 |
≤30kg/cm2 |
≤30kg/cm2 |
|
CHILLER |
|
5P |
5P |
10P |
10P |
MACHINE |
Machine Dimension |
4.2×1.8×2.4(m) |
4.7×2.1×2.4(m) |
5.2×2.1×2.4(m) |
5.2×2.1×2.4(m) |
Machine Weight |
3.0T |
4.5T |
4.0T |
7.0T |
