• Higher Bottle Quality • Higher Speed • Longer Lifespan
| Model | Unit | YW-L4S | YW-L4MSS | YW-L6S | YW-L9S | |
|
Clamping System |
Cavity Quantity |
cavities |
4 |
4 |
6 |
9 |
|
Clamping Force |
KG |
4500 |
5500 |
5600 |
6500 |
|
|
Mould Thickness |
mm |
90 |
125 |
90 |
90 |
|
|
Stretching |
mm |
260 |
350 |
260 |
260 |
|
|
Stretching Rod |
mm |
10 |
12 |
10 |
10 |
|
|
Bottom Mould |
mm |
50 |
50 |
50 |
50 |
|
|
Pitch Distance |
mm |
76.2 |
114.3 |
76.2 |
76.2 |
|
|
Preform Holder |
PCS |
92 |
108 |
126 |
180 |
|
|
Container Spec. |
||||||
|
Max.Container |
ml |
600 |
2000 |
600 |
600 |
|
|
Max.Container |
mm |
260 |
350 |
260 |
260 |
|
|
Max.Container |
mm |
70 |
100 |
70 |
70 |
|
|
Max Preform |
mm |
100 |
170 |
100 |
100 |
|
|
Max.Neck Diameter |
mm |
38 |
38 |
38 |
38 |
|
|
Output |
BPH |
6000-7000 |
6000-6500 |
9000-10000 |
12000-13000 |
|
|
Electrical System |
||||||
|
Heating Oven |
Zone |
5 |
5 |
6 |
10 |
|
|
Number of Lamp |
PCS |
6*5 |
5*10 |
6*6 |
6*10 |
|
|
Heating Power |
KW |
45 |
75 |
54 |
90 |
|
|
Installed Power |
KW |
55 |
88 |
63 |
102 |
|
|
Voltage |
Customized |
|||||
|
Actual Power |
KW |
20-25 |
35-40 |
30-35 |
45-50 |
|
|
Air System |
||||||
|
Operating |
Mpa |
0.7-0.9 |
0.7-0.9 |
0.7-0.9 |
0.7-0.9 |
|
|
Blowing Pressure |
Mpa |
2.5--3.0 |
2.5--3.0 |
2.5--3.0 |
2.5--3.0 |
|
|
High Pressure Air |
L/min |
4.0/40 |
4.0/40 |
6.0/40 |
10.0/40 |
|
|
Chiller System |
||||||
|
Temperature Range |
Degree |
9-13 |
9-13 |
9-13 |
9-13 |
|
|
Pressure |
Mpa |
0.4 |
0.4 |
0.4 |
0.4 |
|
|
Capacity |
HP |
10 |
10 |
10 |
15 |
|
|
Machine |
||||||
|
Machine Dimension |
M |
3.6*1.5*2.08 |
4.7*2.1*2.08 |
4.7*1.9*2.08 |
6.4*2.1*2.08 |
|
|
Machine Weight |
KG |
4000 |
6500 |
6000 |
8000 |
|
