YW-B20L
semi automatic 5 gallon PET

YW-B20L semi automatic 5 gallon PET stretch blow molding machine is especially designed to produce 5-gallon bottle. Its output is up to 120BPH for 5-gallon bottle in certain case.

YW-B20L consists of main machine and rotary infrared heater. The ordinary quartz lamp cannot heat preform ideally because the preform wall is excessively thick. The infrared heater with high penetrative force can heat the outside of preform evenly.What is more,inner heater is included for more transparent bottle.

What an operator should do during production is just to put externally heated preform to inner heater and then transfer to the blow mold and press the switch, and then computer will take care of the whole procedure.

Complete System should include:

  • 1/Main Machine
  • 2/Oven
  • 3/Inner Heater
  • 4/Air Compressor
  • 5/Air Dryer Group
  • 6/Air Tank
  • 7/Air Chiller
  • 8/Blow Mould

Feature

  • 1

    Main machine heavier than others by 200kg,longer by 20cm.

  • 2

    Oven with more perform holders.

  • 3

    Special inner heater is included.

  • 4

    Heating modules are widely found in the oven,instead of adjustable silicone.

  • 5

    The best Chinese heating lamps are fixed.

  • 6

    Bigger Diameter of pneumatic cylinders are installed.

  • 7

    Double-crank clamping system is used.

  • 8

    Special design for PET Gallon Bottle up to 20L.

  • 9

    Using Infrared reheat units to achieve uniform heating throughout the wall of preform .

  • 10

    Adopt special designed preform heating system to ensure the optimal heating effect for thick wall preform.

  • 11

    Special designed fan-cooling system in the heating channels to keep the oven with constant temperature and ensure the preform can be heated completely.

  • 12

    Water cooling system ensures the quality of preform neck.

  • 13

    Up to 120BPH with one-cavity mould for 5-gallon bottle.

  • 14

    Use advanced PLC control system with counting function and time-control precision to 0.01second, and a use-friendly panel.

  • 15

    Equipped with special designed air storage units.

  • 16

    Simple installation, startup & adjustment.

Technical Parameters
YW-B20L ITEM UNIT TECH. DATA
Max.Volume of Product L 20
Output BPH 100-120
Neck Size of Product mm <=160
Useful Area of Mould mm 420*660
Mould Thickness mm 350-420
Mould Stroke mm <=350
Clamping Force KN 80
Stretching Stroke mm 530
Working Pressure Mpa <=1.0
Blowing Air Pressure Mpa <=4.0
Power of Main Blower KW 2
Weight of Main Blower Kg 2500
Dimension of Main Blower mm 2800*720*2160
PRE-HEATER Power of Pre-heater KW 16
Weight of Pre-heater Kg 800
Dimension of Preheater mm 2200*750*1880
